5G Harmonization with Avionics and its Effect on Business Aviation

Starting last January, US cellular telephone companies began using the C-Band 5G networks. These new 5G cellular emissions lie near the frequencies used by Radio Altimeters (also referred to as RADALT and Radar Altimeters) installed in many aircraft. Band leakage from these emissions could degrade performance of the RADALT and other dependent aircraft systems.

In 2020, the Federal Communications Commission cleared additional wireless communications spectrum for 5G use by reallocating the spectrum between 3.7 and 3.98 GHz. This spectrum is near the 4.2-4.4 GHz band used by RADALT. If band boundaries were hard and fast, there would be no concern. However, some equipment in use today can experience band leakage and RADALTs could be susceptible to RF (Radio Frequency) interference received in the band of operation or within adjacent, nearby frequency bands.

POSSIBLE ISSUES

Potential issues are many, diverse, and complex. 5G interference could cause RADALT malfunctions that could produce unreliable results or failure to function, especially during take-off and landing maneuvers. For example, the aircraft navigation system could be prompted to warn the pilots of non-existing obstacles or even fail to warn them in time of the existence of real obstacles. RADALTs may also be integrated with other aviation equipment, including but not limited to TCAS (Traffic Collision Avoidance Systems), TAWS/EGPWS (Terrain Alert Warning Systems), Flight Director and Autopilot systems.

For years, the FAA, the aviation industry, telecommunications companies, and telecom regulators have been discussing and weighing concerns regarding aviation safety due to interference from the expansion of 5G C-Band usage. With all the noise surrounding this issue, many business aviation professionals have downplayed these messages. The time for business aircraft operators to better understand the situation and begin to plan for compliance with upcoming mandates is now.

FAA Rules

The FAA has issued ADs and NOTAMs prohibiting specific operations as well as Alternative Methods of Compliance (AMOCs), and telecommunications companies have scheduled controlled 5G rollouts around popular airports. On Dec 7, 2021, the FAA issued AD 2021-23-12 addressing operational limitations for low-visibility approaches and how they will be applied through NOTAM announcements. More recently, the FAA has acted to release a Notice of Proposed Rulemaking (NPRM) with proposed guidelines for all transport and commuter category airplanes equipped with RADALTs. NPRM 4910-13-P outlines proposed changes to allow for continued safe operation in the 5G frequency environments. Permanent solutions are in work by OEM manufacturers and will come in the form of signal filters, RADALT retrofits, re-designs, and more.

Following are some resources that can help operators better understand this important and dynamic issue. In an effort to keep the industry informed, Duncan Aviation will periodically update this page. So check back often.

FAA/GOVERNMENT 5G INTERFERENCE RESOURCES

Report A RadAlt Anomaly

FAA 14 CFR Part 139

FAA 5G and Aviation Safety

FAA Special Airworthiness Bulletin on Risk of Potential Adverse Effects on Radio Altimeters

NASA’s Callback Safety Reporting System

Telco filing with FCC for Voluntary Mitigations

Fixed-Wing NPRM

Joint Industry Comments Filed Against Fixed-Wing NPRM

OTHER 5G INTERFERENCE RESOURCES

NBAA Shares 5G Concerns

NBAA 5G Interference

NBAA 5G Deployment FAQs

AIN NASA Reports 5G Interference

Gogo 5G Spectrum Interference White Paper

AIN/Collins 5G Interference Webinar

Why 5G Could Be Dangerous Video

RESOURCES ABOUT RADIO ALTIMETERS

How A Radio Altimeter Works

Turkish Airline Flight 1951
(RadAlt failure discussed 5:35-9:20 and at 21:36)

5G Interference Survey
